Matrax Heavy Duty Drivable Composite Mats 1.5 Inch x 3.89 x 3.89 Ft.
(1 Answered Questions)
Be the first to review this product
$214.20/mat
Save 10%
$14.16/sqft
Reg: $238.00/mat
Handling Time Estimate: 12-14 Weeks
- Vertical locking system
- Even load transfer between panels
- Made in USA, 100 percent recyclable
- See More Details
- Vertical locking system
- Even load transfer between panels
- Made in USA, 100 percent recyclable
- Easy to install
- Drive and pedestrian friendly
- Diamond top texture
- Cam lock system
- Portable flooring
Portable event floor, Stadiums and other large-scale venues, Heavy loads such as tractor-trailers, Rigging, and equipment staging platforms. Temporary event parking, Tent flooring, Industrial warehouse flooring, Prefabricated structure flooring, Storage tent, Aircraft hangars, Hardscape protection, ADA compliant beach access walkways
NOTE: This item is a custom order and is not returnable.
Matrax Heavy Duty Drivable Composite Mats Grey 1.5 Inch x 3.89 x 3.89 Ft. - Vertical locking system
Matrax Heavy Duty Drivable Composite Mats 1.5 Inch x 3.89 x 3.89 Ft. can be used as a stadium event flooring and other outdoor events. These heavy duty mats will keep athletic turf protected from the equipment needed to set up stages, tents, and parking areas.
The separate components of the Matrax Heavy Duty Drivable Composite Mats 1.5 Inch x 3.89 x 3.89 Ft. are a turf protection system, constructed to work with one another to produce a cover system that will shield athletic turf surfaces from the stress of non-sporting events. The interlocking panels are designed to tolerate varying kinds of loads, as well as stage setup, large cranes, fully-loaded tractor trailers and other wheeled vehicles. Easy to install and delivers a safe, sturdy and resilient working surface for events. Using a perpendicular lock system, with a four inch overlap flange that connect the panels together, this creates a level surface that is free of tripping hazards.
A strong nylon material is used for the cam lock element that does not rust or corrode, making for a long service life. The cam lock pin delivers the strength essential to allowing two panels to stay locked together when handling. The interlocking system has five retained fasteners per panel that engaged and disengaged by rotating them ninety degrees with the installation tool provided. Can be used with the Matrax Light Duty Pedestrian Composite Mat 3.89 x 3.89 Ft, offering versatility in configurations.
Optional ADA compliant ramps are available to provide safe movement on and off Matrax mats.
Specs:
A strong nylon material is used for the cam lock element that does not rust or corrode, making for a long service life. The cam lock pin delivers the strength essential to allowing two panels to stay locked together when handling. The interlocking system has five retained fasteners per panel that engaged and disengaged by rotating them ninety degrees with the installation tool provided. Can be used with the Matrax Light Duty Pedestrian Composite Mat 3.89 x 3.89 Ft, offering versatility in configurations.
Optional ADA compliant ramps are available to provide safe movement on and off Matrax mats.
Width: 3.89 ft
Length: 3.89 ft
Thickness: 1.5 inch
Sq. ft: 15.13
Usable surface area: 13.5 ft
Weight: 50 lbs
Compression strength: 450 psi
Max wheel load: 300 psi
Max allowable deflection: 3 inch
Surface Dimensions: 4 ft x 4 ft, 1.22 m x 1.22 m
Height: 1.5 in., 38.1 mm
Net Working Surface per Truck: [Based on GVR rating of 80,000 lbs.] 11,340 ft, 21,054 m2
Shipping and Storage: [Max pallet height not to exceed 42 inches] 30 mats / 4 x 4 pallet,60 mats / 4 x 8 pallet
Compression Strength: [Based on an intermittent load on 8 x 8 ft area] 450 psi, 3,100 kps
Maximum Wheel Load: [Rubber tire at < 5 mph with a minimum contact area of 9 in2 over level surface at 72°F] 300 psi, 2,068 kps
Minimum Contact Area for Static Loads: [ > 250 lbs. at 72°F] 16 inch, 210.16 cm2
Maximum Allowable Deflection: 3 inch, 7.62 cm
Temperature Range: [For temperatures out of range, use de-rating. Service Rating Chart] -4 degrees to 113 degrees Fahrenheit, 20 degrees C to 45 degrees Celsius
Burn Rating: [Data is based on the materials used in manufacturing] UL 94-HBN/A
Maintenance
Clean using a pressure washer or garden hose and non-metal scrub brush.
Shipping
Ships via freight delivery, 60 per 4x8 ft pallet, 2 pallets high
This Product Ships Freight Only.
Please review our shipping disclaimer.
| SKU# | 1002-MAT-MXT-HD |
| In Stock | Yes |
| Product Type | Mat |
| Material Type | Polyethylene Plastic |
| Product Edging | Straight |
| Thickness | 1-1/2 inch |
| Width | 3.89 feet |
| Length | 3.89 feet |
| SF per Item | 15.13 |
| Weight | 50.00 lbs |
| Packaging | Shrink Wrapped on Pallets |
| Non Absorbent | Yes |
| Special Adhesives | No |
| Interlock Loss | 0.00 feet |
| Interlocking Connections | No |
| Made In | USA |
| Surface Finish | Diamond |
| Surface Design | Solid color |
| Installation Method | Dry lay, connector pins |
| UV Treated | Yes |
| Reversible | No |
| Border Strips Included | No |
| Manufacturer Warranty | 5 year manufacturer |
View Installation InstructionsProduct Questions:
Q: Would I be able to rest a car on jackstands on this material for extended periods of time?
A: We have not tested this for that application. Our outrigger pads, however, are made for that type of use.
